Automatic 20-color changer
Two heads, 20 needles.
Large embroidery field
Maximum hoop size, up to 500 X 360 mm
Double beam strengthening machine stability and reducing vibration
Reinforced machine support beam, machine weight is 250 kg.
Double drive belt system
The double belt system transmitting the drive provides higher torque, less noise and easier maintenance.
Reinforced square guide rails
Reinforced square guide rails provide greater impact resistance and durability.
Factory-mounted leveling feet
Factory-mounted leveling feet facilitate transport and installation.
Comfortable double LED lighting
Ricoma has equipped the embroidery machine with a double LED lighting system.
Thread trimmer
The machine automatically trims threads.
Versatile
Embroidery on flat surfaces, hats and finished garments.
Needle positioning laser
The laser constantly shows the needle insertion point and allows for perfect pattern positioning (optional).
Ricoma Inspire design program
Ricoma embroidery design program (optional). Link-Get to know Ricoma Inspire
High speed
Maximum speed is 1000 insertions per minute!
Universal cap attachment
Cap embroidery attachments with a 270 degree rotation angle.
Large 8-inch operating panel
The embroidery machine is equipped with an 8-inch color touchscreen display, showing the actual number of needle insertions HD True Color.
Newly developed small arm for sewing high-quality embroidery
The embroidery machine has a newly developed small arm for sewing high-quality embroidery on hats and small items.
Easy to use
The embroidery machine has a user-friendly panel interface. Easy to operate. easy to make an application, add sequins, tape. We can easily change the parameters of the available hoops or thread colors. The display panel is visible at large angles and at the same time adjustable in many directions.
Convenient USB port
The machine has a USB port.
The best looper.
Ricoma has been equipped with a special, fast Japanese Koban Hook looper.
Thread break sensor.
The Ricoma embroidery machine has a thread break sensor that stops the machine.
Emergency STOP
The machine has an immediate, emergency system for stopping the embroidery machine.
Rich additional equipment
New sensational optional attachments that allow you to embroider scarves, ties, shoes and other difficult to put on hoops! Their assembly to the embroidery machine is very easy.
Solid table construction
Very strong and stable table construction. Despite its weight, about 190 kg, it is easy to maneuver.
Pattern memory
We can save 20 million stitches or 200 embroideries.
Support for many file formats
The machine reads many file formats, including DST, DSB and others.
Many transfer options
You can send embroideries to the machine via a cable from a PC, via Wi-Fi or USB key.
Wi-Fi connection
Simple connection to the Internet and Wi-Fi network.
Initial outline of the embroidery field
The machine makes an initial outline of the embroidery, which protects against shaft displacement.
Economical motor
Servo motor 150 W means low power consumption.
Operation under different voltage
The embroidery machine operates with a voltage of 220V (50 Hz)1110V (60 Hz).
Modern stepper motors
The latest DC36V stepper motor with low vibration and low noise has been used.
Easy equipment assembly
You can easily mount accessories for embroidering applications, ribbons or sewing sequins.
Manual thread color change function
You can manually change the thread color from 172 to 196 degrees.
“STOP” rescue button
A convenient, large “STOP” rescue button
Machine dimensions
Machine dimensions: 1910 mm – 770 mm – 1620 mm (L-W-H). The small width of the machine allows easy entry through standard door sizes!
